IPC322LB-SF28(40)-A
2MP Fixed IR Dome Network Camera
• High quality image with 2MP, 1/2.8"CMOS sensor
• 2MP (1920*1080)@30/25fps; 720P (1280*720)@30/25fps
• Ultra 265, H.265, H.264
• Smart IR, up to 30m (98ft) IR distance
• Day/night functionality
• 2D/3D DNR (Digital Noise Reduction)
• IP67 protection
• IK10 vandal resistant
• Support PoE power supply
• 2-Axis
Specification
Accessories
Download
How to buy
 IPC322LB-SF28-AIPC322LB-SF40-A
Camera
Max Resolution2MP
Sensor1/2.8" CMOS
Min. IlluminationColour: 0.01 lux (F2.0, AGC ON)
0 lux with IR on
Day/NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual, 1 ~ 1/100000s
Adjustment AnglePan: 3° ~ 360°, Tilt: 0° ~ 75°
S/N>52dB
WDRDWDR
Lens
Focal Length2.8 mm4.0 mm
Iris TypeFixed
IrisF2.0
Field of View (H)106.7°87.5°
Field of View (V)57.1°46.3°
Field of View (D)115.7°92.4°
DORI
DORI Distance(Lens)2.8mm4.0mm
DORI Distance(Detect)43.4m(142.4ft)62.1m(203.7ft)
DORI Distance(Observe)17.4m(57.1ft)24.8m(81.4ft)
DORI Distance(Recognize)8.7m(28.5ft)12.4m(40.7ft)
DORI Distance(Identify)4.3m(14.1ft)6.2m(20.3ft)
Illuminator
Supplemental LightIR
Illumination Distance(IR)30 m (98.4 ft)
Wavelength850 nm
IR On/Off ControlAuto/Manual
Video
Video CompressionUltra 265, H.265, H.264
H.264 Code ProfileBaseline profile, Main profile, High profile
Frame RateMain Stream: 1080P (1920*1080), Max 30fps; 720P (1280*720), Max 30fps;
Sub Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps
Video Bit Rate128 Kbps ~ 6144 Kbps
U-codeSupport (Main stream)
OSDUp to 4 OSDs
Privacy MaskUp to 4 areas
ROIUp to 8 areas
Video StreamDual Streams
White BalanceAuto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2
Digital Noise Reduction2D/3D DNR
Smart IRSupport
FlipNormal, Flip Vertical, Flip Horizontal, 180°
DewarpingN/A
HLCSupport
BLCSupport
DefogDigital Defog
Events
Basic DetectionMotion Detection
General FunctionWatermark, IP Address Filtering, Access Policy, ARP Protection, RTSP Authentication, User Authentication, HTTP Authentication
Network
ProtocolsIPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, UPnP, HTTP
Compatible IntegrationONVIF (Profile S, Profile T) , API, SDK
User/HostUp to 32 users, 2 user levels: administrator and common user
SecurityPassword Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, WSSE and Digest Authentication for ONVIF
ClientEZStation, EZView, EZLive
Web BrowserPlug-in free live view: Chrome 57.0 and above, Firefox 58.0 and above, Edge 16 and above
Interface
Audio I/ON/A
Alarm I/ON/A
Serial PortN/A
Built-in MicN/A
Built-in SpeakerN/A
WIFIN/A
Network1 x RJ45 10M/100M Base-TX Ethernet
Video OutputN/A
Certification
EMCCE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035)
FCC (FCC 47 CFR part15 B)
SafetyCE LVD (EN 62368-1)
CB (IEC 62368-1)
UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1)
EnvironmentCE-RoHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU)
ProtectionIP67 (IEC 60529)
IK10 (IEC 62262)
General
PowerDC 12V±25%, PoE (IEEE 802.3af)
Power consumption: Max 5.0W
Power InterfaceØ 5.5 mm coaxial power plug
DimensionsΦ109 x 81mm (Ø4.3” x 3.2”)
Weight0.35kg (0.77lb)
MaterialMetal + Plastic
Working Environment-30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity: ≤95% RH (non-condensing)
Storage Environment-30 °C ~ 60 °C (-22 °F ~ 140 °F), Humidity: ≤95% RH (non-condensing)
Surge Protection4KV
Reset ButtonN/A
Web Client Language1 Language
English
