| Device Specifications | Description |
| Video decoding | H.264, H.265 |
| Camera connection | Max 16 channels |
| Image composition | Supports composition of 2, 3, 4, or 6 images |
| Image operations | Image storage, search, view, export, and uploads |
| Image OSD | Text OSD including plate number, time, location, lane etc., on single or composite images |
| File Transfer Protocol | FTP, SFTP |
| Hard disk storage | Supplied with 1*4TB hard disk Expansion to 4 * 3.5” SATA disk, up to 8TB each |
| External interfaces | Description |
| Network interface | Dual NICs with support for dual‑network isolation dual‑network interconnection. NIC1: 16 * Gigabit Ethernet interfaces (RJ45). NIC2: 2 * Gigabit optical interface, 4 * Gigabit Ethernet interfaces (RJ45). |
| Protocol | TCP/IP, HTTP, HTTPS, SFTP, FTP etc |
| USB interface | 2 * USB 3.0, compatible with USB 2.0 |
| Serial interface | 2 x RS‑232, 2 x RS‑485 |
| Alarm input | 2 x alarm input (phoenix connector) |
| Audio | 1 x Audio port |
| Alarm output | 2 x alarm output (phoenix connector) |
| Power output | DC12V, 500mA |
| Power input | DC12V, 10A |
| Hardware Parameter | Description |
| Power consumption | < 30W (with 1 HDD, and heating module off) < 85W (with 1 HDD, and heating module on) < 110W (with HDD fully configured, and heating module on) |
| Operating temperature | ‑30ºC to 70ºC |
| Operating humidity | 5% to 95% (noncondensing) |
| Weight | With 1 supplied HDD: < 7kg Fully loaded with HDD: < 9kg |
| Dimensions | 350mm(W) × 320mm(D) × 72mm(H), Rack mountable |
| Certification | Description |
| EMC | CE EMC: EN 55032: 2015+A11:2020+A1:2020 EN 55035: 2017+A11:2020 EN 61000‑3‑3: 2013+ A1:2019+A2:2021 EN IEC 61000‑3‑2: 2019+A1:2021 |
| Safety | CE LVD:EN IEC 62368‑1:2020+A11:2020 |
