IPC262EB-HDX10K-I0-MA
2MP Lighthunter WDR Network IR Bullet Camera（ Only for Morocco）
• High quality image with 2MP,1/2.8’’ CMOS sensor
• 1920*1080@60fps in the main stream
• Ultra 265, H.265, H.264, MJPEG
• Five streams offer more choices for different clients in an integrated solution
• 10X optical zoom allows for closer viewing of subjects
• Smart intrusion prevention, support false alarm filtering, include Cross Line, Intrusion, Enter Area, Leave Area detection
• Face capture, automatic selection of best snapshots
• LightHunter technology ensures ultra-high image quality in low illumination environment
• Up to 150 dB Optical WDR (Wide Dynamic Range)
• Built-in heater, support normal start-up at low temperature
• DC12V or AC24V or PoE+(IEEE 802.3at) power supply
• Wide voltage range of ±25% in AC, -10%~+25% in DC
Specification
Accessories
Download
How to buy
 IPC262EB-HDX10K-I0-MA
Camera
Sensor1/2.8", 2.0 megapixel, progressive scan, CMOS
Min. IlluminationColour:0.002 lux (F1.6, AGC ON)
0 lux with IR
Day/NightIR-cut filter with auto switch (ICR)
ShutterAuto/Manual, 1 ~ 1/100000s
WDR150dB
S/N＞52dB
Lens
Lens type5~50mm@F1.6, AF automatic focusing and motorized zoom lens
IrisDC-iris
Angle of View (H)4.71°~55.87°
Angle of View (V)2.65°~33.21°
Angle of View (O)5.56°~68.72°
DORI
DORI DistanceLens (mm)Detect (m)Observe (m)Recognize (m)Identify (m)
582.2(269.8ft)32.9(107.9ft)16.4(54.0ft)8.2(27.0ft)
50977.6(3207.3ft)391.0(1282.9ft)195.5(641.5ft)97.8(320.7ft)
Illuminator
IR RangeUp to 100m (328.1 ft) IR range
Wavelength850nm
IR On/Off ControlAuto/Manual
Video
Video CompressionUltra 265, H.265, H.264, MJPEG
Frame RateMain Stream: 2MP (1920*1080),Max 60fps;
Sub Stream: 1080P (1920*1080), Max 60fps;
Third Stream: D1 (720*576), Max 60fps;
Fourth Stream: D1 (720*576), Max 60fps;
Fifth Stream: D1 (720*576), Max 60fps;
Video Bit Rate128 Kbps~16 Mbps
H.264 TypeBaseline Profile/Main Profile/High Profile
H.265 TypeMain Profile
U-codeSupport
ROIUp to 8 areas
Video streamFive streams
OSDUp to 8 OSDs
Privacy MaskUp to 4 blacks in the same picture
White BalanceAuto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2
Digital noise reduction2D/3D DNR
Smart IRSupport
FlipNormal/Flip Vertical/Flip Horizontal/180°/90°Clockwise/90°Anti-clockwise
HLCSupport
BLCSupport
DefogDigital Defog
Intelligent
Smart intrusion preventionSupport false alarm filtering: Line crossing detection, Intrusion detection, Region entrance detection, Region exit detection
RecognitionFace capture
Events
Basic DetectionMotion detection, Audio detection, Tampering alarm
General FunctionWatermark, IP Address Filtering, Alarm input, Alarm output, Access Policy, ARP Protection, RTSP Authentication, User Authentication
Audio
Audio CompressionG.711U, G.711A
Audio Bitrate64 Kbps
Two-way AudioSupport
SuppressionSupport
Sampling Rate8KHz
Storage
Edge StorageMicro SD, up to 256 GB
Network StorageANR,NAS(NFS)
Network
ProtocolsIPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS
Compatible IntegrationONVIF (Profile S, Profile G, Profile T), API, SDK
User/HostUp to 32 users. 2 user levels: administrator and common user
SecurityPassword protection, strong password, HTTPS encryption, Export operation logs, basic and digest authentication for RTSP, digest authentication for HTTP, TLS 1.2, WSSE and digest authentication for ONVIF
ClientEZStation
EZLive
EZView
Web BrowserPlug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+
Interface
Audio I/O1/1
Alarm I/O2/1
Serial Port1 RS485
Built-in MicN/A
Built-in SpeakerN/A
Built-in HeaterSupport
WIFIN/A
Network1 * RJ45 10M/100M Base-TX Ethernet
Video Output1 BNC
Certification
EMCFCC CFR 47 Part 15
EN 55032:2015
EN 55024:2010
EN 61000-3-2:2014
EN 61000-3-3-2013
SafetyIEC 62368-1
EN 62368-1
UL 60950-1
EnvironmentCE-ROHS (2011/65/EU;(EU)2015/863); WEEE (2012/19/EU); REACH (Regulation (EC) No 1907/2006)
ProtectionIngression protection: IP67 (IEC 60529-2013)
Vandal resistant: IK10 (IEC 62262:2002)
General
PowerDC 12V(-10%,+25%) ,AC 24V(±25%), PoE+ (IEEE 802.3at)
Power consumption: Max 13W
Power Interface Wires with cold-pressed terminal
Dimensions (L x W x H)354 x 105 x 98mm (13.9“ x 4.1“ x 3.9”)
Weight1.93kg(4.25lb)
Working Environment-40℃~60℃(-40°F ~ 140°F)，Humidity: ≤95% RH (non-condensing)
Storage Environment-40℃~70℃(-40°F ~ 158°F)，Humidity: ≤95% RH (non-condensing)
Surge protection6KV
Vandal ResistantIK10
Ingress ProtectionIP67
Reset buttonSupport
