| Model | MW3565-T-P |
| Panel | |
| Backlight | DLED backlight |
| Panel size | 65 inches |
| Resolution | 3840*2160 |
| Brightness (cd/m²) | 350 |
| Contrast ratio | 1200:1 |
| Response time (ms) | 8 |
| Color support | 1.07 billion colors |
| Viewing angle (H/V) | 178°/178° |
| Aspect Ratio | 16:9 |
| Refresh Ratio | 60HZ |
| Android | |
| CPU architecture | GK6760V100 |
| CPU operating frequency | Octa-core A55,1.2GHz |
| GPU | MailG52 MP2 |
| RAM/ROM | DDR4: 4GB eMMC: 32GB |
| System version | Android 12.0 |
| Touch | |
| Touch control | Contactless IR sensor, supports 20-point touch |
| Touch Accuracy (mm) | ±1 |
| Glass | 4mm tempered glass, level 7 on Mohs hardness scale, anti-glare |
| Response time (ms) | ≤8 |
| Input method | Opaque objects (e.g. fingers, pens) |
| Microphone | |
| Microphone | Built in Microphone |
| Distance | 6 meter |
| Interface | |
| Interface | 2*HDMI IN(4K)、3* USB3.0、2*USB 2.0、2*touch USB、1* Type C、1* RJ45 IN、1* SPDIF、1* Earphone、1* TF、1*RS232、Power Button * 1 |
| Audio | |
| Speaker | 2×15W |
| Wi-Fi | |
| Configuration | Wi-Fi 5, supports 5G/2.4G |
| Performance | 0~12m distance in open space |
| NFC | |
| NFC | Optional |
| Camera | |
| Camera | Optional |
| Bluetooth | |
| Version | 5.0 |
| Performance | 12m transmission distance in open space |
| Wireless Screen Mirroring | |
| System | Support Windows, MAC, IOS, Android system |
| Whiteboard Application | |
| Whiteboard Application | support |
| OSD | |
| Language | English (Multi-Language Support) |
| VESA | |
| Wall mount hole (mm) | 500*400 |
| General | |
| Power input | AC 100 to 240V, 50/60Hz |
| Overall power consumption (W) | ≤180 (without OPS) |
| Standby power consumption (W) | <0.5 |
| Operating temperature | 0°C to 40°C |
| Operating humidity | 10% to 80% RH, non-condensing |
| Storage temperature | -20°C to 60°C |
| Storage humidity | 10% to 90% RH, non-condensing |
| Product dimensions (W*H*D)(mm) | 1483.8*902*115.8 |
| Packaging dimensions (W*H*D)(mm) | 1615.8*220*1028 |
| Weight (kg) | Net weight: 45.5 Gross weight: 56 |
| Accessories included | 1*power cable, 2* Touch Pen, 1*quick guide, 1*IR remote controller,1* wall mounting bracket,1*HDMI cable |
| LED Life | 30000 hours or above |
| Certifications | CE、RoHS |
| *Note | *The specifications listed above may vary with device model |
