Content of Data Sheet
Product model	CAB-LC3100UCB
Product specification	HSYV-6 4×2×0.52
Test Standard	ISO/IEC11801、TIA-568-C.2
Conductor	Material	OFC(Oxygen free copper)
	AWG	23
	Nom.O.D.(mm)	0.55 ± 0.005 mm
	DC resistance	≤95 Ω/km
Insulation	Material	HDPE
	Thickness	0.2±0.02 mm
	Diameter	0.98±0.05 mm
	Color	Blue/White- Blue	Green/White-Green
		Orange/White-Orange	Brown/White-Brown
Pitch	Offset pitch	≤20 mm
	Cable pitch	≤120 mm
Sheath	Material	PVC(complies RoHS/REACH)
	External O.D.	6.00±0.3 mm
	Color	Orange
	Tensile strength	>13.5 Mpa
	Thickness	0.6±0.05 mm
Surface Printing	Letter height	3.0±0.3 mm
	Color	Black
	Print error & Space	1±0.005 m
	Case number	Yes
Packing	Packing	Carton
	Once packing dimension	420mm205mm420mm
	Twice packing dimension	450mm440mm445mm
	Twice packing quantity	2 cases
Packing length	305±1m
Rip-cord	Yes		Crossing backbone	Yes
Ambient temperature	-20℃～60℃
